Description

THIS IS A DIGITAL DOWNLOAD OF 3D-PRINTABLE FILES. PURCHASE A PHYSICAL KIT HERE.

Downloaded files are for personal use only / not for resale or other unauthorized distribution.

Designed for mounting to a off-the-shelf, telescopic pool cleaning pole (typ. 27-29mm diameter). Fanless / vented design for passive cooling of internal equipment. Printable without supports.

We recommend printing with ASA filament (excellent UV resistance) for outdoor use. Requires brass threaded inserts and socket-head stainless hardware. Bulkhead fittings (power/data and antenna) are optional with purchase but required for use of this enclosure.

Weather resistant when mounted in the correct orientation (vents facing down).

Necessary hardware:

• M4x4x6 Heat-Set Insert Brass Knurled Nuts (Qty: 12) Amazon
• M2x2x3.2 Heat-Set Insert Brass Knurled Nuts (Qty: 10) Amazon
• M4x8 Hex Socket Head Cap Screw Bolts (Qty: 12) Amazon
• M2x4 Hex Socket Head Cap Screw Bolts (Qty: 10) Amazon

IMPORTANT! Antenna Bulkhead Options:

• If you are using the suggested JMT power amplifier, you will need the Type-N (male) to SMA (female) connector.
• If you are using ONLY the WisBlock 4631, you will need the Type-N (male) to IPX/u.fl connector.

For use with the following components (not included / sold separately):

• RAK WisBlock 4631 kit (required)
• JMT Two-Way LoRa Power Amplifier (optional)
• MakerFocus 3.7V 10,000mAh Lithium Polymer Rechargeable Battery (required)
• Antenna with Type-N (male) connector (required)
• Solar panel with USB-C output (recommended)
• Telescopic Pool Cleaning Pole (recommended)

NO WARRANTY / NO RETURNS ON DIGITAL DOWNLOADS.

Designed by SECTION 6 in Florida, USA. All rights reserved.
